100W LED Street Light with ISTMT Report

The 100W LED street light adopts high-efficiency Philips LEDs and a high end programmable LED driver, with a light efficiency of up to 160LM/W, which can replace the 250W traditional HPS street light and can provide LM79, LM80, ISTMT, TM-21, LM84, LM82 and other test reports from third-party laboratories which have ISO17025 certification.

Key features

100w led street light


Wide power range: 20W~240W.

Luminaire efficacy: Up to 170 lm /w.

70% energy saving, short ROI period.

Up to 100, 000hrs @ L70, low maintenance cost.

World-class, approbated quality components (LEDs /Driver /etc.)

Tool-less opening of driver box, ease of maintenance.

Support horizontal and vertical mounted, suitable for different light poles.

High-pressure die-cast aluminum and Tempered glass cover.

More than 10 types of light distributions for optional.

Power-off protection makes the power automatically off when the fixture is opened.

A smooth body would greatly diminish dust accumulation and bird droppings heap up.

The level bubble makes it easy for the installer to adjust the position of the lamp.

1500 hours salt spray test report.



Applications

Local roads, Express roads, Town roads, Residential area roads, Pedestrian crossings, Parking areas


Datasheet

LED street light 100w price


Specifications
ModelMK-SE2-100
LED BrandLumileds 3030/5050
Driver BrandMeanwell or Inventronics
Normal Wattage100W
Input Voltage100-240/277VAC/DC12/24V
Power Efficiency>90%
Power Factor>0.95
Lamp Rated Luminous Efficiency155-165 lm/w
Lamp Rated Lumen output15500-16500lm (Lumen tolerance +/- 5%)
Color Rendering Index70( 80 optional)
Color Temperature3000K or 4000K or 5000K or 5700K
Optic (IESNA)Type II Medium;Type III Medium
Optimal Operating Temperature25°
Storage Temperatures-40°C~50°C
Working EnvironmentBetween-40°C~+50°C,   10%~90%RH
Total Harmonic Distortion< 10%
Lumen Maintenance> 100000 hours -L70, @25 ºC (77 ºF)
Wind IndexForce 12
BodyDie-cast  aluminum Housing and Tempered glass
CoverPC lens
Pole Fitter Diameter60mm ( 50mm optional)
RatingIP66 IK10
Protection Class I ( Class II optional)
SPD10KV (20KV optional)
CertificationCE,ROHS,ENEC,CB,LM80,LM79,IP66,IK10
Dimming Options1-10V or DALI or PWM or Timer
Available on requestNEMA socket (3/5/7pins), ZHAGA socket, Short cap, Photocell, Motion sensor, Knife switch, NTC, OLC, Solar Compatible, DALI Dimming
Warranty5 years







Download

FAQ

What is the ISTMT test?

Temperature Measurement in-SITU (ISTMT)

It is the temperature of the LED source casing within the LED system (luminaire or lamp) while it is working in its intended location and/or environment (In "SITUation"). The measurement is made at the temperature measuring point (Tc Point) specified by the manufacturer of the LED package.

As a LED street light manufacturer, MKLIGHTS can provide ISTMT test reports, if you need them, please contact the MKLIGHTS team.

What is the use of the ISTMT report?

ISTMT is a thermal measurement of the LED source chip included inside the LED luminaire or lamp when fitted according to the manufacturer's specifications. The measurement is made using the temperature measuring point (TMP) specified by the manufacturer of the LED package as Tc or Ts.

ISTMT is used to calculate lifetimes based on TM-21 calculations and should be used in combination with the LM-80 test report.

Our in-situ temperature measurement test (ISTMT) report is based on a single sample and is done in compliance with Annex A of IES LM-84-14.

What is the LM 79 test report?

The LM-79 standard evaluates the performance of devices that include solid-state lighting (SSL) technology, such as light-emitting diodes (LEDs). This testing captures performance under defined operational circumstances at a certain moment in time.

As a LED street light manufacturer, MKLIGHTS can provide LM79 test reports, if you need them, please contact the MKLIGHTS team.
