90w wire hanging street lights are common in European cities, especially in Denmark where they can be seen everywhere on the street. SC street lights are designed with tool-less buckle for easy maintenance and standard with 10KV SPD, knife switch, respirator, and optional Philips and Osram programmable LED driver for NTC, OLC functions.
Die-cast aluminum housing with flat tempered glass.
Toolless is open for easy installation, replacement, and maintenance.
Power-off protection makes the power automatically off when the fixture is opened.
A smooth bodywould greatly diminish dust accumulation and bird droppings heap up.
Possible energy savings of more than 70%. 100,000 hours lifetime saving maintenance cost.
The LED engine, consisting of the LED light source and the power supply, can be easily replaced or upgraded. Designed for easy technology upgrade (Future Proof)
Electronic temperature monitoring prevents overheating of LEDs and power supply.
Provided with 10KV Surge Protection Devices.
Corrosion-resistant polyester powder painted 100µm in thickness.
Meets a 1000-hour salt spray certification per ASTM B117/ ISO 9227:2012.
Optimized roadway photometric distributions, ULOR = 0 (zero uplight)
Post-Top Mounted, Pendant Mounted, Side Entry Mounted, Suspended Mounted for optional.
Supports Smart City application,7-Pin NEMA socket, and standard outdoor dimming protocols.
e.g. photocell, motion sensor, DALI, 1-10V.
CE/ RoHS/ IK08/ IP66 / LM80/ LM79.
7 years limited warranty available.
Application:
Urban Roads, Urban Street, Parks and gardens, Residential areas
| Specifications | |
| Model | MK-SCX-90( X= 1,2,3,4) |
| LED Brand | LUMILEDS® LUXEON 3030 or 5050 |
| Driver Brand | Meanwell HLG series/ Inventronics |
| Normal Wattage | 90W |
| LED Chip Quantity | 3030: 168pcs 5050: 84pcs |
| Input Voltage | 100-240/277VAC |
| Power Efficiency | >90% |
| Power Factor | >0.95 |
| Lamp Rated Luminous Efficiency | 130-150 lm /w |
| Lamp Rated Lumen output | 11700-13500 lm (Lumen tolerance +/- 5%) |
| Color Rendering Index | 70(80 optional) |
| Color Temperature | 3000 or 4000 or 5000 or 5700K |
| Photometric Type | Type I Medium; Type II Medium; Type III Medium; TypeV, Short |
| Optimal Operating Temperature | 25℃ |
| Storage Temperatures | -40°C~50°C |
| Working Environment | Between-40°C~+50°C, 10%~90%RH |
| Total Harmonic Distortion | < 10% |
| Lumen Maintenance | > 100,000 hours -L70, @25 ºC (77 ºF) |
| Wind Index | Force 12 |
| Body and Shell Materials | Die-cast aluminum; Tempered Glass |
| Pole Fitter Diameter | 60mm |
| Rating | IP66 IK08 |
| Protection | Class I ( Class II optional) |
| SPD | 10KV (20KV optional) |
| Certification | CE, ENEC,CB ROHS,LM80,LM79,IP66 IK08,ISTMT |
| Dimming Options | 1-10V or DALI or PWM or Timer |
| Control Options | Photocell or Motion sensor or Smart control |
| Color Options | Deep grey |
| Warranty | 7 years |
What is a hanging street light?
Suspended or hanging street lights are street lights mounted on wire ropes, common street lights are usually installed on poles, but in some European countries, street lights are suspended in the air by wire ropes, which are fixed to buildings on both sides of the street, heard the purpose is to prevent the light poles from affecting traffic.
What do I need to pay attention to when buying hanging street lights?
1. The lamps should not be too heavy. Because the suspended street light is suspended on the wire rope, if the weight is too heavy, it will cause the wire rope to sag or break, and that will be very dangerous.
2. Pay attention to the spectral direction when installing. As the installation position of suspended street light is not fixed, it can be in the middle of the road or on both sides of the road, and the street light spectrum is generally asymmetric spectrum, so it is very important to choose the right spectrum according to the installation position, otherwise, it will lead to poor road uniformity.
3. The fixture fixed parts must be firm. As the fixture are suspended on the wire rope, they will bear a lot of wind, the lamps and lanterns will always shake, and if the fixed parts are not firm, they will easily fall down and cause injuries to people.
