80w led street light with 7pin Nema socket and Short cap
80w led street light with 7pin Nema socket and Short cap
80w led street light, Philips led street light 80w,80w led street light price,80w equivalent led streetlight, led street light
Features:
Terse Design of appearance
Die casting aluminum housing
Good heat dissipation effect, the optimized heat dissipation structure is designed
IP66 and IK08 waterproof grade meet the
High temperature and high humidity environment use
Strobe-free stable optical output, power factor 0.95, Maintain the stability of the power grid
Can be with adjustable arms(vertically or horizontal mounted), the Angle range is ±15°, adjust beam angles according to different occasions
High efficacy more than 130lm/w
The product is smart and convenient to transport, and the transport cost is very low
High performance but very competitive price
Area Application:
Urban and residential area
Pedestrian category roads
Vehicle category roads
Traffic routes and main access road
Parking areas
Cycling track
Footpath
80w led street light with 7pin Nema socket and Short cap
80w led street light, Philips led street light 80w,80w led street light price,80w equivalent led streetlight, led street light
| Specifications | |
| Model | MK-SH2-80 |
| LED | Epistar (Default) / Lumileds(for optional) |
| Driver | FUJING |
| Wattage | 80W |
| Working Voltage | AC100-265V｜50/60Hz |
| PF | PF＞0.9 |
| Luminaire efficacy | 130 lm /w |
| Luminaire flux | 10400lm |
| CRI | Ra>70 (Default) / Ra>80 |
| CCT | 3000K, 4000K, 5000K, 6000K |
| Optic lens | Type II Medium;Type III Medium |
| Mounting Type | Side entry or Vertical pole mounted ±15° |
| Storage Temperatures | -40°C~50°C |
| Working Environment | -20℃～+50℃，10%～90%RH |
| THD | <15% |
| Lifetime | ＞50,000hrs |
| Materials | High-pressure die-cast aluminum, UV-resistant Polycarbonate |
| Holder | 50mm/60mm(Default) |
| Rating | IP66 IK08 |
| Protection | Class Ⅰ(Default)/Class II |
| Surge Protection Device | 10KV (20KV optional) |
| Certifications | CE, RoHS, LM79, LM80, TM-21, IP66, IK10 |
| Dimming Options | 1-10V Dimming /Timer Dimming |
| Available on request | Solar Compatible, NEMA socket (3/5/7pins), ZHAGA socket, Short cap, Photocell, Motion sensor, NTC, OLC, DALI Dimming |
| Body color | Dark Grey/Black/Light Grey (available on request) |
| Warranty | 5 years |
80w led street light with 7pin Nema socket and Short cap
80w led street light, Philips led street light 80w,80w led street light price,80w equivalent led streetlight, led street light
80w led street light with 7pin Nema socket and Short cap
80w led street light, Philips led street light 80w,80w led street light price,80w equivalent led streetlight, led street light
