90w philips street light

90w Philips street light adopts high quality and high-efficiency Philips LED chips, High-end Philips programmable LED driver, quality is comparable to Philips street light, but the price is much better.

Key features

90w Philips street light

Philips street light, Philips street light price, Philips led street light price, Philips led street light, led street lamp


Wide power range: 60W~130W.

Special circuit design, single LED damage won't affect others' normal work.

Smart design, low transportation costs.

Toolless open for easy installation, replacement, and maintenance.

The LED engine, consisting of the LED light source and the power supply, can be easily replaced or upgraded. Designed for easy technology upgrade (Future Proof)

Electronic temperature monitoring prevents overheating of LEDs and power supply.

Provided with 10KV Surge Protection Devices.

Corrosion-resistant polyester powder painted 100µm thickness.

Meets a 1000-hour salt spray certification per ASTM B117/ ISO 9227:2012.

Optimized roadway photometric distributions, ULOR = 0 (zero uplight)

Supports Smart City application,7-Pin NEMA socket, and standard outdoor dimming protocols.

e.g. photocell, motion sensor, DALI, 1-10V.

High Lumen output up to 160lm/w with high-quality LED chips.

Designed to last at least 100, 000 hours at L70.

ENEC/ CB/ CE/ RoHS/ IK10 /IP66 /LM79

5 years limited warranty available.



Applications

Street, highway, park lot, roadway, path and etc

Datasheet

90w Philips street light

Philips street light, Philips street light price, Philips led street light price, Philips led street light, led street lamp


Specifications
ModelMK-SD2-90+
LED BrandLUMILEDS® LUXEON 3030
Driver BrandMeanwell / Inventronics
Normal Wattage90W
LED Chip Quantity3030: 160pcs
Input Voltage100-240/277VAC
Power Efficiency>90%
Power Factor>0.95
Lamp Rated Luminous Efficiency150 lm /w
Lamp Rated Lumen output13500lm (Lumen tolerance +/- 5%)
Color Rendering Index70(80 optional)
Color Temperature3000 or 4000 or 5000 or 5700K
Photometric TypeTypeII Medium
Optimal Operating Temperature25℃
Storage Temperatures-40°C~50°C
Working EnvironmentBetween-40°C~+50°C, 10%~90%RH
Total Harmonic Distortion<10%
Lumen Maintenance>100,000 hours -L70, @25 ºC (77 ºF)
Wind IndexForce  12
Body and Shell MaterialsDie-cast aluminum; PC Lens
Pole Fitter Diameter60mm ( 50mm optional)
RatingIP66  IK10
Protection Class  I
SPD10KV (20KV optional)
CertificationCE, ENEC,CB ROHS,LM80,LM79,IP66 IK10,ISTMT
Dimming Options1-10V
Control OptionsPhotocell or Smart control
Color OptionsDeep grey
Warranty5  years



Description

Philips street light, Philips street light price, Philips led street light price, Philips led street light, led street lamp

90w philips street light

Video

90w Philips street light

Philips street light, Philips street light price, Philips led street light price, Philips led street light, led street lamp

Download

FAQ

  1. How many lumens is a street light?

    If you're still used to measuring light output in watts, don't worry, because there are still plenty of people who use this method to measure it. So to help you get used to specify the number of lumens you need for LED outdoor lighting, here's a cheat sheet for you.

  2. How much does a street light cost?

    Typically, a street lamp can cost between $2,000 and $3,000. Streetlights can cost $1,000 to install, depending on the area. But costs can vary widely. The type of lighting system and power supply chosen will affect the cost of installation and maintenance of these streetlights.

  3. How much does a street light cost per month?

    The average price in the US is 10 cents per KWH (us $0.10 / KWH). Power consumption for 12 hours is (12 hours x 100 watts) = 1200 watt hours = 1.2 KWH. So the daily electricity bill is (1.2kwh *$0.10) = $0.12. Monthly electric street lamp cost is ($0.12*30) = $3.60.

  4. How many watts is a street light?

    "The size and consumption of the lights used in street lamps (typically between 35 and 250 watts) varies, depending on whether they illuminate residential areas, main roads or city centers." "It is generally assumed that the average wattage of street lamps is about 80 watts."
