100W LED High Bay Light adopts high-efficiency Philips LEDs and Driver, the whole light efficiency is up to 190LM/W, it can replace 250W MH lamps, the energy-saving rate is up to 60%, it is the best choice for industrial lighting, as the factory of UFO high bay light, MKLIGHTS offers free industrial lighting simulation design.
100W LED High Bay Light, UFO high bay light, industrial light, UFO bay light, high bay light factory
The energy-efficient design delivers up to 190 lm /w
70% energy saving, short ROI period
Durability, suitable for dry and wet applications
Multiple lighting distributions are available
Versatile in mounting with wall-mounted, loop hanging, steel chain hanging
Multiple lighting control options are available, e.g. DALI, 1-10V, Motion sensor
RoHS compliant, environmentally friendly, no mercury or lead, 100% recyclable
5 years warranty
Applications
Warehouse, factory, rink, area and etc.
100W LED High Bay Light, UFO high bay light, industrial light, UFO bay light, high bay light factory
| Specifications | |
| Model | MK-BD-100S |
| LED Brand | Lumileds LUXEON 3030/2835 |
| Driver Brand | MOSO series |
| Norminal Wattage | 100W |
| LED Quantity | 3030: 172pcs 2835: 602pcs |
| Input Voltage | 100-240/277VAC |
| Power Efficiency | >90% |
| Power Factor | >0.95 |
| Lamp Rated Luminous Efficiency | 140-190lm/w |
| Lamp Rated Lumen output | 21000-28500lm (Lumen tolerance +/- 5%) |
| Color Rendering Index | 70 (80 is optional) |
| Color Temperature | 3000, 4000, 5000 or 5700K |
| Photometric Type | 60,90,110 degrees |
| Optimal Operating Temperature | 25℃ |
| Storage Temperatures | -40°C~50°C |
| Working Environment | Between-40°C~+50°C, 10%~90%RH |
| Total Harmonic Distortion | <10% |
| Lumen Maintenance | >50,000 hours -L70, @25 ºC (77 ºF) |
| Body | Die-cast Aluminum Housing |
| Cover | PC lens |
| Rating | IP65 IK08 |
| Protection | Class I |
| Certification | CE, ROHS, LM80 |
| Dimming Options | 1-10V or DALI or PWM or Timer |
| Control Options | Motion sensor or Smart control |
| Color Options | Black |
| Warranty | 5 years |
100W LED High Bay Light, UFO high bay light, industrial light, UFO bay light
100W LED High Bay Light, UFO high bay light, industrial light, UFO bay light, high bay light factory
Any light that hangs at least 20 feet above the ground is designated a high bay light. The term "high bay" is used because these lights are often installed in industrial or commercial bays. Frequently, chains, hooks, or pendants are used to mount high bay fixtures to ceilings. Additionally, they may be mounted directly to the ceiling.
Industrial and Manufacturing Facilities
Assembly Lines
Workshops
Large Retail Stores
Recreational facilities, gyms
Event Centers
Aircraft hangars
Barns
Subway/Transit
Parking Garages
Utilize LEDs - LED bulbs to consume far less energy and generate more light than other kinds of bulbs, resulting in considerable cost savings, particularly when illuminating thousands of square feet in a manufacturing or retail establishment. Utilize Lighting Automation — At the very least, you should utilize timers to control when high bay lights are on or dimmed. For example, a retail business may dim the lights at closing time, then turn them off one hour later to allow employees time to leave. Furthermore, motion sensors may be used to regulate high bay lighting, allowing the lights to turn off after a period of inactivity, resulting in even higher energy savings. This is particularly beneficial in locations where traffic patterns vary during the day.
