High Bay Led Lighting Prices

With competitive price BD series high bay led lighting fixture adopts UFO design, 60, 90, and 120-degree beam angles can be selected, high-efficiency Philips LEDs and high-efficiency SOSEN driver are selected, the efficiency is up to 190LM/W, and the energy-saving rate is up to 80% or more, suitable.

Key features

High Bay Led Lighting Prices | China Factory

High Bay Led Lighting Prices, ufo led lights, ufo lights led, led high bay lighting price, high bay lighting fixtures


150w industrial lighting with high efficacy

The energy-efficient design delivers up to 190 lm /w

70% energy saving, short ROI period

Durability, suitable for dry and wet applications

Multiple lighting distributions are available

Versatile in mounting with wall-mounted, loop hanging, steel chain hanging

Multiple lighting control options are available, e.g. DALI, 1-10V, Motion sensor

RoHS compliant, environmentally friendly, no mercury or lead, 100% recyclable

5 years warranty



Applications

Warehouse, factory, rink, area and etc.

Datasheet

High Bay Led Lighting Prices | China Factory


Specifications
ModelMK-BD-100S
LED BrandLumileds  LUXEON 3030/2835
Driver BrandMOSO series
Norminal Wattage100W
LED  Quantity3030: 172pcs 2835: 602pcs
Input Voltage100-240/277VAC
Power Efficiency>90%
Power Factor>0.95
Lamp Rated Luminous Efficiency140-190lm/w
Lamp Rated Lumen output21000-28500lm (Lumen tolerance +/- 5%)
Color Rendering Index70  (80 is optional)
Color Temperature3000K, 4000K, 5000K or 5700K
Beam angle60,90,110 degrees
Optimal Operating Temperature25℃
Storage Temperatures-40°C~50°C
Working EnvironmentBetween-40°C~+50°C, 10%~90%RH
Total Harmonic Distortion<10%
Lumen Maintenance>50,000 hours -L70, @25 ºC (77 ºF)
BodyDie-cast Aluminum Housing
CoverPC lens
RatingIP65 IK08
Protection Class  I
CertificationCE, ROHS, LM80
Dimming Options1-10V or DALI or PWM or Timer
Control OptionsMotion sensor or Smart control
Color OptionsBlack
Warranty5 years



Description

High Bay Led Lighting Prices | China Factory

High Bay Led Lighting Prices

Video

High Bay Led Lighting Prices | China Factory

Download

FAQ

What Kelvin should I select for my LED high bay lights?

Color is measured in Kelvins, which is a scientific unit of measurement. It is a measurement of how much yellow or blue is present in the lamp's light spectrum. Higher Kelvin values indicate whiter light rather than brighter light. While 4000K and 5000K are the most common Kelvins for high bay lights, they may also be made in 2200K, 3000K, 3500K, 4000K, 5000K, and 5700K, as well as in colors, 590nm, and No-UV.

5700K – 5700 Kelvin is used for applications including video and photography. A frequent option ordered with 5700K is 90+ CRI, high color rendering.

5000K – 5000 Kelvin LED high bay lights are the most common and are ideal for illuminating warehouses, and manufacturing facilities, commercial spaces requiring accurate lighting.

4000K – 4000 Kelvin LED high bay lights to emit white that is warmer than 5000K. 4000K is frequently found in offices, warehouses, and big box stores. This is partially due to the past prevalence of fluorescent and metal halide lights which were 4100K.

3500K – 3500 Kelvin is sometimes called neutral as it is neither white like higher Kelvins nor as yellow as warmer Kelvins. 3500 Kelvin is frequently found in upscale retail applications.

3000K – 3000 Kelvin is a warm color light that matches the light emitted by halogen light fixtures. 3000K is more white than the light emitted by an incandescent lamp such as the light emitted by a light bulb in a fine dining restaurant.


Should I retrofit old high bay lights or buy new LED high bay lights?

There isn't a simple answer to this question as the number of high bay fixtures required to illuminate and area for your application depends on multiple factors including your application. The list below includes some of the questions that need to be answered to determine the quantity of high bay LED fixtures required for your facility.

What is the size of the area to be illuminated?

Obviously, the bigger the area is, the more lights are required to illuminate the area. The dimensions of the facility are required to determine the number of fixtures.

How many lumens are emitted by each fixture?

If one high bay light emits 20,000 lumens and another high bay light emits 40,000 lumens you may think that you would need half as many fixtures if you selected the 40,000-lumen fixture. That may be correct, but what if the 40,000-lumen high bay is too intense relative to the mounting height, or provides too much light underneath the light and insufficient light levels nearby? Light has to be evenly distributed to be appropriate and effective.

What is the mounting height of the fixtures?

The mounting height partially determines the maximum lumens that can be emitted without the light becoming too intense or producing too much glare. For example. 15,000 lumens might work at a 15-foot mounting height, but 30,000 lumens would be too intense. Also, with increased mounting heigh you achieve superior light distribution.

What is the Max/Min ratio required for the application?

The max/min ratio is the maximum light in the area divided by the minimum light in the area. For most sports, the max/min required is less than 3.0. According to IESNA, a walkway for general use at night should be a max/min of 10 or less, but if the guests using the walkway are residents of an assisted living facility, the max/min should be less than 5.0. You need to know how even the light needs to be for your application and that specification is in turn met by the spacing/distribution of the light fixtures.

What is the application of the area?

The function performed in the facility determines the footcandles (FC) of light required on the work surface. A large warehouse used for storage requires lower FC as compared with a facility where small electronics are being assembled. Tasks with high contrast and large size require 30 FC on the work surface, while tasks with low contrast and small size require 100fc.
