high efficiency 100w best ufo led high bay lights

100W Best UFO LED High Bay Lights, UFO design, simple and elegant appearance, with Philips LEDs and SOSEN high-efficiency driver, the whole light efficiency is up to 190LM/W, can replace 400W traditional sodium lamps, supports hanging ring or bracket installation, suitable for warehouses, workshops, indoor parking, etc.

Key features

100W Best UFO LED High Bay Lights

Best ufo led high bay lights, ufo low bay led lights, led ufo lights, high bay led ufo lights, led ufo high bay lights


The energy-efficient design delivers up to 190 lm/w

70% energy saving, short ROI period

Durability, suitable for dry and wet applications

Multiple lighting distributions are available

Versatile in mounting with wall-mounted, loop hanging, steel chain hanging

Multiple lighting control options are available, e.g. DALI, 1-10V, Motion sensor

RoHS compliant, environmentally friendly, no mercury or lead, 100% recyclable

5 years warranty



Applications

Warehouse, factory, rink, area and etc.

Datasheet

100W Best UFO LED High Bay Lights

Ufo low bay led lights


Specifications
ModelMK-BD-100S
LED BrandLumileds  LUXEON 3030/2835
Driver BrandMOSO series
Normal Wattage100W
LED Quantity3030: 172pcs 2835: 602pcs
Input Voltage100-240/277VAC
Power Efficiency>90%
Power Factor>0.95
Lamp Rated Luminous Efficiency140-190lm/w
Lamp Rated Lumen output21000-28500lm (Lumen tolerance +/- 5%)
Color Rendering Index70  (80 is optional)
Color Temperature3000K, 4000K, 5000K, or 5700K
Photometric Type60,90,110 degrees
Optimal Operating Temperature25℃
Storage Temperatures-40°C~50°C
Working EnvironmentBetween-40°C~+50°C, 10%~90%RH
Total Harmonic Distortion<10%
Lumen Maintenance>50,000 hours -L70, @25 ºC (77 ºF)
BodyDie-cast Aluminum Housing
CoverPC lens
RatingIP65 IK08
Protection Class  I
CertificationCE, ROHS, LM80
Dimming Options1-10V or DALI or PWM or Timer
Control OptionsMotion sensor or Smart control
Color OptionsBlack
Warranty5 years




Description

100W Best UFO LED High Bay Lights

High bay led ufo lights

high efficiency 100w best ufo led high bay lights

Video

100W Best UFO LED High Bay Lights

led ufo lights


Download

FAQ

How do this Fixture Benefits Commercial and Industrial areas?

Before purchasing a UFO LED High Bay Light, you should understand how the fixture can benefit commercial and industrial sectors.

Simple to Install: When you purchase the UFO High Bay Fixture, you will get an installation instruction booklet that details the step-by-step installation method. If you are familiar with wiring, you may install the fixture yourself; otherwise, you can hire a professional to do it for you.

Broad Beam Angle: The fixture has a wide beam angle that illuminates a large portion of your commercial and industrial environment. A 120° beam angle is sufficient to illuminate a larger area with high lumen lighting output.

Dimmable: What could be better than being able to regulate the brightness of your lighting? This fixture enables you to adjust the light to your liking. You may minimize energy usage by dimming the light from 10V to 1V.

Low-cost Maintenance: If you use HID fixtures on a daily basis, you are probably aware of the hefty maintenance costs. This fixture needs little maintenance until its 50,000-year lifetime expires.

Premium LED Chip: The fixture's most significant component is its LED cob chips. This fixture was made using Lumileds LED SMD chips, which provide crisp and bright light to the surface.


What Features make a UFO LED High Bay Light Special?

A UFO High Bay Light provides the following advantages over HID fixtures:

Thermal Heat Dissipation: This fixture has a large heat sink dissipation with aluminum fings, which promotes longevity, improves operating efficiency, and keeps the fixture cool. The fixture's housing is composed of aluminum, which is an excellent conductor of heat.

Correlated Color Temperature & Color Rendering Index: The color temperature describes the color of the lighting output, which is 4000K (Natural White Light) & 5700K (Day White Light), and these two CCTs are ideal for brightening a large area. Although CRI impacts the purity and quality of light, a CRI of greater than 80 aids with object sight.

IP65 Rated: This grade indicates that the fixture can withstand heavy dust, water, insects, and harsh weather conditions.

How Do I select which High Bay Lighting should be Used?

A few general rules of thumb can help you decide what sort of high bay fittings you'll need.

First, consider how high you want to put your LED lighting.

Second, the number of fixtures you will need is heavily influenced by your lighting application.

Third, how much lighting automation and energy savings do you want (factory, warehouse, production area, aisles ways)? For example, do you want your high bay fixtures to turn off on their own, or do you mind turning them on and off at night every day? By opting for automation, lighting design and product selection may result in significant energy savings.

Fourth, how are your UFO LED high bay light fixtures going to be wired? There are two alternatives here: hard-wiring and using a cable and plug. The simplicity of installation of these lights is obvious in both of these wiring solutions.

Fifth, how do you want to install your UFO LED lights? A high bay light has the advantage of being able to be hung in the same location as earlier high-pressure sodium lights or huge metal halides. This enables a rapid and simple installation and replacement of outdated lighting technology.

Lumen output vs. watt output of these lights might vary greatly across brands. They may differ significantly and should be a major deciding factor.

The spread of light and optics also have a significant effect on the dispersion of light along the surface of the area being illuminated.

Be wary of poor ufo-led high bay light items that employ sub-par components in lighting fixtures. Some issues with faulty components might result in premature wear and flickering lights.
