100w Solar Street LED Light

100W integrated solar street light adopt ALL IN TWO design. lithium battery and controller are integrated with LED street light, the solar panel is separated, the system divides into 2 parts. since the solar panel is installed on the top of the pole, of solar panel wattage can be very big, and the angle can be adjusted to the best position.

Key features

Solar street led light


Wide power range: 30W~120W.

Solar panel + led chip + charge controller + battery all in two box.

High Lumen output up to 170lm/w with high-quality LED chips.

Innovative split structural design, with good heat dissipation performance.

Adjustable LED module angle, satisfying various road lighting needs.

Brand new A+ class LifePO4 battery with large capacity, support 10 days working after fully charging.

Adopting imported high-brightness Bridgelux 3030 and 5050 led chips, lab testing luminous efficiency up to 210lm/w.

High-efficiency Monocrystalline silicon Solar Panel to generate electricity (Higher efficiency than Polysilicon)

With intelligent discharge management, Charge and discharge soft and hard dual protection, and intelligent equalization technology, deep cycle more than 2000 times.

Constant current discharge stable lighting + Night sensor + PIR motion sensor + Time Controller(6,8,10,12hrs for choose)+remote control(Above 30w).

Very easy disassemble, installation and transportation.


Applications

Courtyard, Garden, Park, Street, Roadway, Pathway, Parking Lot, Private Road, Sidewalk

Datasheet

Semi Integrated Solar Street Light


Specifications
ModelMK-SSC-100
LED Number192units
Nominal Power100W
Battery Spec.LifePO4  Battery(12.8V 54AH)
Solar Panel Spec.18V 130W(Imported High-Efficiency Monocrystalline Silicon)
LED BrandBridgelux  3030 High-Efficiency LED Chip
Lamp efficiency170lm/w
Luminous Flux17000lm
Viewing Angle140°
CCT2700-6500K
Charge time5-6  hours by bright sunlight
Discharge time12hours/day,backup  5-7 days
Discharge Temperature-20℃~+60℃
Charge temperature<60℃
Lighting mode3hrs  100% brightness+2hrs 80% brightness+7 hrs 25% brightness
Mounting height9-12M
Space between light32-42M
Lamps material of mainHigh-class aluminum alloy
RatingIP65 IK10
Induction TypeMicrowave induction function
CertificationCE, ROHS, LM80
Warranty  period3   years


Download

FAQ

What is integrated all in one solar street light?

The term "all in one" refers to a new generation of solar led street lights that combine solar panels, batteries, controllers, and LED lights into a single lamp body.

What is integrated street light?

A solar panel and LED luminary with built-in Lithium-ion / Lithium Ferro Phosphate battery (LiFePO4) battery and solar driver card with charge controller make up an integrated solar street light.

What is semi integrated solar streetlight?

The solar cell, controller, and battery are all combined into a semi-integrated solar street light, but the bulb is isolated by a cable.
