This is a solar street light project in the United Arab Emirates, using our SSA series integrated solar street lights, LED modules, battery panels, lithium batteries, and the controller are integrated into a whole unit, the customer does not need wiring or assembly, and is directly fixed to the light pole can be used.
Project location: UAE
Project time: 2017
Project details:
60W All in one solar street light, Model: MK-SSA706030, 5700K, 1S, 70W Mono solar panels, 36AH Lithium battery, motion sensor, pole height=6m, 70 sets
solar powered street lights, All in One Solar light, solar parking lot lights, outdoor solar street lights, best solar street lights, solar powered street light
Specifications | |||
Model | MK-SSA706030 | ||
LED Number | 90units | ||
Nominal Power | 60W | ||
Battery Spec. | 30AH /12.8V | ||
Solar Panel Spec. | Monocrystal 70W /18V | ||
LED Brand | Philips Lumileds 3030 2D | ||
Luminous Flux | 7800lm | ||
Light type | 1S | ||
CCT | 3000K.4000K.5000K.5700K | ||
Charge time | <5 Hours (Low battery voltage) | ||
Worktime at Energy -saving Model(30%) | more than 22 hours | ||
Discharge Temperature | -20℃~+60℃ | ||
Charge temperature | <60℃ | ||
Light control voltage | 5-11V | ||
mounting height | 6-8m | ||
space between light | 18-35m | ||
Pole Diameter Fixture | Round pole: Φ60~85mm; Square pole : 60 x60 ~77 x77mm | ||
Rating | IP65 IK10 | ||
Induction Type | Human infrared induction or microwave induction function | ||
Certification | CE, ROHS, LM80 | ||
Warranty period | 3 years |
Specification_SSA_All in one solar street light.pdf
Installation Manual_AIOSolarStreetLight_SSA2.pdf
Related Products:
solar powered street lights | solar powered street light | solar parking lot lights |
outdoor solar street lights | best solar street lights | All in One Solar light |
Related Projects:
10 Important Facts About Led Street Light | Advantages and Prospects of LED Street Lights |
LED street lamps VS high-pressure sodium lamps | Standard for lighting design of urban road |
What is All in One Solar street light?
The All In One Solar street lamp is a new-age compact lighting solution that combines solar panels, LED lights, lithium-ion or lithium iron phosphate batteries, and a PIR motion sensor. The all-in-one solar street lamp uses solar panel voltage to detect day/night conditions.
How do all in one solar street lights work?
Here's how it works. When the sun rises and the temperature in the area rises, the sensor tells the LED to turn off. As temperatures rise further, it prompts solar panels to harness the sun's energy. The energy used will be stored in the battery.
Do solar panels work at night?
While solar panels still work on cloudy days, they don't work at night. The reason is simple: Solar panels work on a scientific principle called the photovoltaic effect, in which solar cells are activated by sunlight to produce an electric current.
