40W LED Low Bay Lights

40W LED low bay light adopts modular design, single module 40W, flexible power, excellent heat dissipation, the temperature of Ts point is lower than 50°, can be used in high-temperature environment, beam angle of 60, 90 and 110° is optional, low bay light usually mounts lowly, so the power is generally less than 100W, and a big beam angle is used.

Key features

Led low bay light, led low bay light, low bay light, low bay light fixtures, low bay led lights


Wide power range: 40W~300W.

Special circuit design, single LED damage won't affect others' normal work.

High output lumen efficiency, up to 170lm/W.

Corrosion-resistant polyester powder painted 100µm in thickness.

Over 10 optical lenses are available for virtually any application.

Modular design for easy installation, replacement, and maintenance.

Variety applications with different mounting Accessories.

Multiple lighting control options are available, e.g. DALI, 1-10V, and Motion sensor.

Designed to last at least 100,000 hours at L70

UL/ DLC/ SAA/ CB/ CE/ RoHS/ IK10 /IP66 /LM79

7 years limited warranty available.



Applications

Warehouse, factory, rink, area and etc

Datasheet

led low bay light, Led low bay light, low bay light, low bay light fixtures, low bay led lights

Specifications
ModelMK-BB1-40
LED BrandLumileds LUXEON 3030/5050
Driver BrandMeanwell HLG series
Normal Wattage40W
LED Module Quantity1 module
Input Voltage100-240/277/347/480VAC
Power Efficiency>90%
Power Factor>0.95
Lamp Rated Luminous Efficiency145-170lm/w
Lamp Rated Lumen output5800-6800lm (Lumen tolerance +/- 5%)
Color Rendering Index70(80 is optional)
Color Temperature3000, 4000, 5000 or 5700K
Photometric Type60,90,110 degrees
Optimal Operating Temperature25℃
Storage Temperatures-40°C~50°C
Working EnvironmentBetween-40°C~+50°C, 10%~90%RH
Total Harmonic Distortion<10%
Lumen Maintenance>100,000 hours -L70, @25 ºC (77 ºF)
BodyStretching  Aluminum
CoverPC  lens
RatingIP66  IK10
Protection Class  I ( Class II optional)
CertificationCE, ROHS, LM80
Dimming Options1-10V or DALI  or PWM or Timer
Control OptionsMotion  sensor or Smart control
Color OptionsSilver
Warranty7  years

Description

led low bay light, led low bay light, low bay light, low bay light fixtures, low bay led lights

40w led low bay lights

Video

led low bay light, led low bay light, low bay light, low bay light fixtures, low bay led lights


Download

FAQ

What is low bay light?

Low bay lights are typically designed for usage in ceilings with a height of fewer than 20 feet from the floor. Low bay ceilings are the most frequent style of ceiling seen in residences, retail establishments, and public buildings.


What is considered low bay lighting?

Low bay fixtures are only compatible with ceilings between 12 and 20 feet in height. High bay lighting can illuminate ceilings between 20 and 45 feet in height. The illumination strengths also vary. Low bay illumination is less than 100 watts, and high bay illumination may exceed 100 watts.


What's the difference between a low bay and a high bay?

The mounting height is the most noticeable difference between low bay and high bay lights. LED low bays are intended for installation at heights of up to 8 meters. Historically, a low bay was likely the rectangular "white box" that you are more used to seeing in factories, but a high bay was a pendant-style high bay in which the physical features were disregarded.

At LED Save, we categorize a low bay as an unlensed product, often with a 120° beam angle, and a high bay as a lensed product capable of emitting a particular light pattern when installed at a greater height. The primary distinctions between the low bay and high bay lighting are the beam angle and height.
