40W LED low bay light adopts modular design, single module 40W, flexible power, excellent heat dissipation, the temperature of Ts point is lower than 50°, can be used in high-temperature environment, beam angle of 60, 90 and 110° is optional, low bay light usually mounts lowly, so the power is generally less than 100W, and a big beam angle is used.
Led low bay light, led low bay light, low bay light, low bay light fixtures, low bay led lights
Wide power range: 40W~300W.
Special circuit design, single LED damage won't affect others' normal work.
High output lumen efficiency, up to 170lm/W.
Corrosion-resistant polyester powder painted 100µm in thickness.
Over 10 optical lenses are available for virtually any application.
Modular design for easy installation, replacement, and maintenance.
Variety applications with different mounting Accessories.
Multiple lighting control options are available, e.g. DALI, 1-10V, and Motion sensor.
Designed to last at least 100,000 hours at L70
UL/ DLC/ SAA/ CB/ CE/ RoHS/ IK10 /IP66 /LM79
7 years limited warranty available.
Applications
Warehouse, factory, rink, area and etc
led low bay light, Led low bay light, low bay light, low bay light fixtures, low bay led lights
| Specifications | |
| Model | MK-BB1-40 |
| LED Brand | Lumileds LUXEON 3030/5050 |
| Driver Brand | Meanwell HLG series |
| Normal Wattage | 40W |
| LED Module Quantity | 1 module |
| Input Voltage | 100-240/277/347/480VAC |
| Power Efficiency | >90% |
| Power Factor | >0.95 |
| Lamp Rated Luminous Efficiency | 145-170lm/w |
| Lamp Rated Lumen output | 5800-6800lm (Lumen tolerance +/- 5%) |
| Color Rendering Index | 70(80 is optional) |
| Color Temperature | 3000, 4000, 5000 or 5700K |
| Photometric Type | 60,90,110 degrees |
| Optimal Operating Temperature | 25℃ |
| Storage Temperatures | -40°C~50°C |
| Working Environment | Between-40°C~+50°C, 10%~90%RH |
| Total Harmonic Distortion | <10% |
| Lumen Maintenance | >100,000 hours -L70, @25 ºC (77 ºF) |
| Body | Stretching Aluminum |
| Cover | PC lens |
| Rating | IP66 IK10 |
| Protection | Class I ( Class II optional) |
| Certification | CE, ROHS, LM80 |
| Dimming Options | 1-10V or DALI or PWM or Timer |
| Control Options | Motion sensor or Smart control |
| Color Options | Silver |
| Warranty | 7 years |
led low bay light, led low bay light, low bay light, low bay light fixtures, low bay led lights
led low bay light, led low bay light, low bay light, low bay light fixtures, low bay led lights
Low bay lights are typically designed for usage in ceilings with a height of fewer than 20 feet from the floor. Low bay ceilings are the most frequent style of ceiling seen in residences, retail establishments, and public buildings.
Low bay fixtures are only compatible with ceilings between 12 and 20 feet in height. High bay lighting can illuminate ceilings between 20 and 45 feet in height. The illumination strengths also vary. Low bay illumination is less than 100 watts, and high bay illumination may exceed 100 watts.
The mounting height is the most noticeable difference between low bay and high bay lights. LED low bays are intended for installation at heights of up to 8 meters. Historically, a low bay was likely the rectangular "white box" that you are more used to seeing in factories, but a high bay was a pendant-style high bay in which the physical features were disregarded.
At LED Save, we categorize a low bay as an unlensed product, often with a 120° beam angle, and a high bay as a lensed product capable of emitting a particular light pattern when installed at a greater height. The primary distinctions between the low bay and high bay lighting are the beam angle and height.
