150w Gas Station Led Canopy Retrofit | RC-150R

Gas stations generally use canopy design, and gas station lighting fixtures are generally recessed in the canopy. As a supplier of gas station lighting fixtures, MKLIGHTS can provide professional lighting retrofit solutions and high-quality gas station retrofit canopy lamps.

Inquire Now None

Key Features Datasheet Description Video Download FAQ

Key features

150w Gas Station Led Canopy Retrofit

gas station canopy led retrofit, led canopy lights for gas station, gas station canopy led lights for sale, led lights for gas station canopy, led gas station canopy lights

Up to 100,000hrs @ L70, low maintenance cost

World class, approbated quality components (LEDs /Driver /etc.)

Tempered glass cover, easy for cleaning

Compact die-cast structure, solid mechanism and reliable quality

ATEX certification allows the lamps to be used safely in flammable and explosive areas

Optional installations accessories for recessed, surface and bracket mounting

CE/ RoHS/ IK10 /IP66

Multiple lighting distributions available

Multiple lighting control options are available, e.g. DALI, 1-10V, Motion sensor

5 years warranty

Applications

Petrol station, Gas station, Warehouse, Logistic hall, Toll station, Exhibition center, Workshop

Datasheet

150w Gas Station Led Canopy Retrofit

gas station canopy led retrofit, led canopy lights for gas station, gas station canopy led lights for sale, led lights for gas station canopy, led gas station canopy lights

Specifications
Model	MK-RC-150R
LED Brand	Lumileds LUXEON 3030
Driver Brand	INVENTRONICS
Norminal Wattage	150W
LED Quantity	192pcs
Input Voltage	100-240/277/347/480VAC
Power Efficiency	>90%
Power Factor	>0.95
Lamp Rated Luminous Efficiency	155 lm/w
Lamp Rated Lumen output	23250 lm (Lumen tolerance +/- 5%)
Color Rendering Index	70 (80 is optional)
Color Temperature	3000K, 4000K, 5000K or 5700K
Photometric Type	60°, 90° or 120°
Optimal Operating Temperature	25℃
Storage Temperatures	-40°C~50°C
Working Environment	Between-40°C~+50°C, 10%~90%RH
Total Harmonic Distortion	< 10%
Lumen Maintenance	> 100,000 hours -L70, @25 ºC (77 ºF)
Body	High pressure die-cast aluminum
Cover	UV-resistant Polycarbonate+Tempered glass
Rating	IP66 IK10
Protection	Class I ( Class II optional)
Certification	CE,ROHS,LM80
Dimming Options	1-10V or DALI or PWM or Timer
Control Options	Motion sensor or Smart control
Color Options	White
Warranty	5 years

Description

150w Gas Station Led Canopy Retrofit

gas station canopy led retrofit, led canopy lights for gas station, gas station canopy led lights for sale, led lights for gas station canopy, led gas station canopy lights

150w gas station canopy led retrofit

Video

150w Gas Station Led Canopy Retrofit

gas station canopy led retrofit, led canopy lights for gas station, gas station canopy led lights for sale, led lights for gas station canopy, led gas station canopy lights

Download

Catalog

FAQ

What kind of lights retrofit kits do gas stations use?

Canopy lighting is the most prevalent type of lighting retrofit kits seen in gas stations. Frequently, LED gas station canopy lights are put in canopies covering gas pumps.

What kind of lights retrofit kits do gas stations use?

All of our gas station canopy lights can be customized frame size, such as 400x400mm, 600x600mm and other common sizes

You just tell us your requirements, we have professional structural designers tailor-made for your gas station
