120W LED Canopy Light Fixtures for Oil Station

120W LED canopy lights for oil petrol station uses a modular design with excellent heat dissipation, easy for maintenance and upgrading, equipped Philips LEDs and Meanwell LED drivers, high light efficiency, long life, recessed installation, suitable for places with canopies, Such as petrol stations, toll stations, etc.

Key features

Led canopy light fixtures

Wide power range: 40W~200W

Special circuit design, single LED damage won't affect others' normal work

Modular design for easy installation, replacement, and maintenance.

High Lumen output up to 140lm/w with high quality LED chips

Multiple lighting control options are available, e.g. DALI, 1-10V, Motion sensor

Designed to last at least 100,000 hours at L70

Multiple lighting distributions are available

CE/ RoHS/ IK10 /IP65

7 years limited warranty available.



Applications

Gas station, Toll station, Petrol station and etc

Datasheet

Petrol pump canopy led lights

Specifications
ModelMK-RA3-120
LED BrandLumileds  LUXEON 3030
Driver BrandMeanwell HLG series
Nominal Wattage120W
LED Module Quantity3 modules
Input Voltage100-240/277/347/480VAC
Power Efficiency>90%
Power Factor>0.95
Lamp Rated Luminous Efficiency140lm/w
Lamp Rated Lumen output16800 lm (Lumen tolerance +/- 5%)
Color Rendering Index70 (80 is optional)
Color Temperature3000,  4000, 5000 or 5700K
Photometric Type110 degrees
Optimal Operating Temperature25℃
Storage Temperatures-40°C~50°C
Working EnvironmentBetween-40°C~+50°C, 10%~90%RH
Total Harmonic Distortion<10%
Lumen Maintenance>100,000 hours -L70, @25 ºC (77 ºF)
BodyStretching  Aluminum
CoverPC  lens
RatingIP65  IK10
Protection Class  I ( Class II optional)
CertificationCE, ROHS, LM80
Dimming Options1-10V or DALI  or PWM or Timer
Control OptionsMotion sensor or Smart control
Color OptionsWhite
Warranty7  years



Download

FAQ

  1.  Why does the gas station need to be LED canopy lights?

    Canopy lighting has advanced greatly and shifted away from HID, pulse start, and fluorescent lighting in favor of more popular, energy-efficient, and cost-effective LED lighting. Canopy lighting is a word that refers to outdoor lighting that is often suspended, recessed or surface affixed to the overhang, ceiling, or soffit of a building. Typically, lighting is used to illuminate places frequented by humans and automobiles. This style of light is utilized in a wide variety of applications, including hotel canopy lighting, parking canopy lighting, and gas station lighting.

    Petroleum is a highly flammable and carcinogenic hydrocarbon. When it comes to handling hazardous substances such as hydrocarbons, one of the primary concerns is the possibility of igniting by electric equipment and machinery. Lighting fixtures located near petroleum storage tanks must have the required safety elements, since they may act as an ignition source if they generate sparks during operation. The majority of commercial lighting fixtures, such as canopy lights, are equipped with high-intensity discharge lamps such as metal halide, high-pressure sodium, or mercury vapor lamps (if the buildings are really old). Fluorescent lights are used in a variety of industrial and commercial applications. However, typical canopy lights have flaws that make them very inefficient. While traditional canopy light fixtures are still in use today, they are inefficient and waste a lot of power.

    The LED versions of these lights are intended to immediately replace their more fragile and energy-intensive equivalents, obviating the high maintenance and electricity needs associated with traditional lighting fixtures. Retrofit LED canopy lights make installation simple by using existing mounting hardware and aligning with existing screw holes. Upgrades to lighting fixtures may be made incrementally while maintaining a uniform lighting format and design across a building. LED canopy lights are designed to survive the harsh circumstances of an outdoor setting, have an IP rating, use less energy, and need less maintenance.

    Many gas station owners are often hesitant to upgrade their canopy lighting from incandescent to LED. Their primary fear is that they may accidentally under-light important regions. This misunderstanding is sometimes fueled by the dramatic power savings associated with LED conversions. The reality is that this is a mistaken notion. Gas stations equipped with LEDs seem far brighter than those illuminated with regular bulbs. None of them are dimly illuminated, and they all glow brightly at night. LEDs provide a light that is uniform in color and brightness.

    If you're starting from scratch, you have total control over the LED lighting fixtures you choose. However, if you already have canopy lights, you'll need to locate an LED alternative that complements the style. Our canopy LED lighting lights are designed specifically for retrofits and readily integrate into existing layouts. With an unrivaled assortment of forms, sizes, model kinds, and trim choices, we ensure that you'll be able to locate the ideal lighting fixtures for every imagined application. Please contact us with any queries regarding our LED canopy lighting fixtures and/or other items.
