560w LED stadium light with module design, luminous efficiency up to 150LM/W, 15,30,45 and 60 degrees beam angle for optional, standard 10KV surge protector, IP66 and IK10, mounting bracket 0-360 degrees rotatable, can be installed on the pole, ground, or wall.
Up to 840W, max lumens is 126,000lm
Special circuit design, single LED damage won't affect others' normal work
Modular design for easy installation, replacement, and maintenance.
Mounting bracket for 360-degree adjustment
Multiple lighting control options are available, e.g. DALI, 1-10V
Designed to last at least 100,000 hours at L70
Multiple lighting distributions are available
CE/ RoHS/ IK10 /IP66
5 years limited warranty available.
Applications
Stadium, arena, golf course, tennis court, Airport, crossroad
| Specifications | |
| Model | MK-FA-560 |
| LED Brand | Philips LUXEON 3030 2D |
| Driver Brand | INVENTRONICS DRIVER |
| Normal Wattage | 280W |
| LED Quantity | 896Pcs |
| Input Voltage | 100-240/277VAC, 50/60Hz |
| Power Efficiency | >90% |
| Power Factor | >0.95 |
| Lamp Rated Luminous Efficiency | >150lm/w |
| Lamp Rated Lumen output | 84000 lm (Lumen tolerance +/- 5%) |
| Color Rendering Index | Ra>70 |
| Color Temperature | 3000, 4000, 5000 or 5700K |
| Photometric Type | 15, 30, 45, 60 degrees |
| Optimal Operating Temperature | 25℃ |
| Storage Temperatures | -40℃~+50℃ |
| Working Environment | Between-40°C~+50°C, 10%~90%RH |
| Total Harmonic Distortion | <10% |
| Lumen Maintenance | >100,000 hours -L70, @25 ºC (77 ºF) |
| Body and Shell Materials | Stretched Aluminium Alloy |
| IP Rating | IP66 with a test report |
| Certification | CE, ROHS |
| Optional Function | 1-10VDC Dimming |
| Warranty | 5 years |
How much do LED stadium lights cost?
The price of led sports lighting fixtures cannot be standardized due to the brand and source of the product. However, the total cost of a traditional high school football/soccer field is between $ 35,000 and $120,000.
How many lumens is a stadium light?
LED stadium lights begin at approximately 60,000 lumens to replace a 1500 watt metal halide sports lighter and increase to an average of 150,000 lumens. Lumens refer to the amount of light emitted by a fixture and are distinct from the amount of light emitted by the ground, referred to as footcandles.
How many lights are in a football stadium?
Typically, a standard training and entertainment football field measuring approximately 100*60m requires the installation of 24-28 1000W stadium lights producing approximately 200 or 300 lux.
