IK10 30w led street light in accordance with EN 62262

IK10 30w led street light in accordance with EN 62262

Key features

IK10 30w led street light in accordance with EN 62262

30w led street light, street light led 30w, IK10 led street light, 30w led street light price

IP66 waterproof/dustproof/explosion-proof/IK09

Aluminum shape good at heat dissipation

The lamp post can be adjusted to plus or minus 15 degrees

It can also be installed vertically

Philips SMD 3030/ 5050/ Ra>70/SDCM<6

100,000 times switching cycle before failure

Total harmonic distortion (THD)<10%

Excellent post light control design, the whole lamp can achieve T II-M, T III-M, That's our advantage

Pass 3G vibration test

Application

It is mainly applied to the road lighting of the urban expressway, secondary, trunk roads, branch road, factory, school, garden, various residential communities, and courtyards. The installation height is 6-13m and the installation torque is 16Nm.


Datasheet

IK10 30w led street light in accordance with EN 62262

30w led street light, street light led 30w, IK10 led street light, 30w led street light price

Specifications
ModelMK-SG1-30
LED LUMILEDS®   LUXEON 3030 or 5050
DriverMeanwell   / Inventronics
Wattage30W
Voltage100-240/277VAC/347V/480VAC
PF>0.95
Luminaire efficacy130-150   lm /w
Luminaire flux3900-4500   lm (Lumen tolerance +/- 5%)
CRI70(80   optional)
CCT3000K   or 4000K or 5000K or 5700K
Optic lensType   II Medium;Type III Medium
Optimal Operating Temperature25℃
Storage Temperatures-40°C~50°C
Working EnvironmentBetween-40°C~+50°C,   10%~90%RH
THD<   10%
Lifetime>   100,000 hours -L70, @25 ºC (77 ºF)
Wind resistanceForce   12
MaterialsDie-cast   aluminum; Tempered Glass
Pole Fitter Diameter60mm   ( 50mm optional)
RatingIP66   IK08
Protection Class   I ( Class II optional)
Surge Protection Device10KV   (20KV optional)
CertificationsCE,   ENEC,CB ROHS,LM80,LM79,IP66 IK08,ISTMT
Dimming Options1-10V   or DALI or PWM or Timer
ControlsPhotocell   or Motion sensor or NEMA or ZHAGA for Smart control
Body colorDeep   grey or Light grey
Warranty5   years



Description

IK10 30w led street light in accordance with EN 62262

30w led street light, street light led 30w, IK10 led street light, 30w led street light price

IK10 30w led street light in accordance with EN 62262

Video

IK10 30w led street light in accordance with EN 62262

30w led street light, street light led 30w, IK10 led street light, 30w led street light price


Download

FAQ


Packing Details
Fixture Dimension551x316x139 mm
Fixture Weight      6.55kg
Packing Dimension595x370x200mm
Packing Weight      8.05kg
